Description
About this Product
Designed to fit seamlessly into kitchens requiring ADA heights, with flexible loading and quiet performance. Auto door open releases steam at the end of the cycle, while AirCurtain technology helps protect surrounding cabinetry.
Features
- SEAMLESS INTEGRATION. — Designed for seamless integration, this dishwasher fits flush with surrounding cabinetry, including installations requiring ADA-compliant heights. Customize with a front panel and handle to match the kitchen space, supporting flexible design choices. With quiet performance and simple installation, it’s designed to enhance both the kitchen aesthetic and the everyday experience.
- FLEXIBILITY FOR EVERYDAY USE (16 PLACE SETTINGS) — Accommodates 16 place settings with flexible solutions including a third rack, adjustable middle rack, and a combination of pitch-adjustable and foldable tines. An external indicator light signals cycle completion, so you know exactly when it’s ready to unload.
- INTELLIGENT CARE FOR EVERY LOAD (7 CYCLES) — Seven wash programs, including Auto, adapt to the needs of each load for consistently effortless results. The Sanitize modifier provides extra protection by eliminating 99.9% of bacteria*, giving greater confidence when caring for everyday items. *Certified to NSF/ANSI Standard
- EFFORTLESS DRYING WITH AIRCUTAIN — At the end of the cycle, the door automatically opens to release excess steam, while innovative AirCurtain technology creates a protective barrier, helping to safeguard surrounding cabinetry over time. Combined with the Dry+ modifier, this ensures effective drying with reduced energy use.
- DESIGNED TO MINIMIZE IMPACT — Recognized as Energy Star Most Efficient, this dishwasher is designed to help reduce water and energy use by minimizing resource consumption. It supports a lower household footprint while delivering consistent, high performance.
- CONNECTED FOR EVERYDAY EASE (SMARTHQ™) — Introducing the SmartHQ™ App - Now you’re in control, wherever and whenever. Get the most out of your Wi-Fi enabled appliance with Smart HQ making it easy to connect, control and monitor your smart dishwasher anywhere. You can conveniently access the latest tips, remote status notifications and more.
Documents
Product Sheet (en)
Dimensions Guide (en)
Owner's manual (en)
Installation guide (en)
Highlights
Accommodates round plates up to (lower basket) 12 9/16" | Adjustable height, foldable cupracks | Easy lift adjustable upper basket | Fold down tines | Full width cutlery/utensil tray | Pitch adjustable tines | Place settings 16 | Wine glass supports | Floor light cycle feedback | Internal wash selector | Keylock | Rinse aid indicator light | Smart appliance | Air curtain for bench protection | Auto Door Open Dry | Flood protection | Half load option | Internal tub material Stainless Steel | Motor type Asynchronous | ThermoDry system | Three-stage filtration system | Water usage (per wash cycle) 3.2 g
Specifications
| Place Settings | 16 | Color | Panel Ready | Manufacturer Color | Panel Ready |
| Series Name | Series 7 | Type | Built-In | Silence Rating | 46 dB |
| Height (Min.) | 81.92 cm | Width | 59.69 cm | Class Width | 24" |
| Depth (Without Handle) | 57.46 cm | Filtration System | Y | Silverware Basket | Y |
| Wi-Fi | Y | Number of Cycles | 7 | ADA Compliant | Y |
| Optional Handle kit Contemporary square fine, aluminium AHD5-OBDD-60SX | Handle kit Contemporary square fine, black AHD5-OBDD-60SB | Handle kit Professional round flush AHP3-DWDD-SX | Handle kit Professional round flush, Brass off-stands AHP3DDDW24BA | Handle kit Professional round flush, Dark Copper off-stands AHP3DDDW24DC | |||||
| Technologies SmartHQ™ App | |||||
| Wash Cycles 60 min | Auto | Eco | Heavy | Light | Medium | Rinse | |||||
| Options Dry + | Half load | Sanitise | Wash modifiers: 3 | |||||
| Information 100-120 V | 60 Hz | 10 A | Energy usage: 224 kWh/year | |||||
Accessories
• Handle kit Contemporary square fine, black AHD5-OBDD-60SB
• Handle kit Professional round flush AHP3-DWDD-SX
• Handle kit Professional round flush, Brass off-stands AHP3DDDW24BA
• Handle kit Professional round flush, Dark Copper off-stands AHP3DDDW24DC
