Description
About this Product
This Frigidaire 1.4 cu.ft. over-the-range microwave features a two speed ventilation, automatic sensor cooking, cooktop LED lighting and child lock.
Features
- COOKTOP LED LIGHTING — Make meal preparation and cooking simple with LED lighting that offers a clear, bright view of your cooktop.
- TWO SPEED VENTILATION — Over-the-range microwave doubles as a hood offering ventilation with two fan speeds.
- AUTOMATIC SENSOR COOKING — Microwave automatically adjusts power levels and cooking times to cook a variety of items, effortlessly.
- AUTO-REHEAT OPTIONS — Reheat almost anything at the touch of a button.
Documents
Product Sheet (en)
Dimensions Guide (en)
Owner's manual (en)
Installation guide (en)
Warranty Details (en)
Highlights
Turntable Diameter: 13-5/8" | Turntable On / Off | 26 Touch Pad Buttons | Ducted / Ductless Installation Option | Cooktop Light: LED 6 light Module | Auto-Start Heat Sensor
Specifications
| Weight | 26.76 kg | Lighting | LED Lighting | Ventilation | Y |
| Filters | 2 Charcoal Filters | CFM | 105/300 CFM | Exhaust Fan Speeds | 2 speeds |
| Sensor Cooking | Y | Turntable | Y | Interior Light | Y |
| Auto Defrost | Y | Control Lock | Y | Color | White |
| Capacity | 1.4 Cu. Ft. | Cooking Power | 1000 W | Power Levels | 9 |
| Manufacturer Color | White | Door Hinge | Left | Warranty | 1-Year Parts and Labor |
| UPC# | 012505564826 | Depth (Without Handle) | 41.11 cm | Height | 43.18 cm |
| Width | 60.64 cm | Class Width | 22" to 23.9" | ||
|
Programs Popcorn Button | Veggies Button | Sensor Reheat Button | Potato Button | 4 Melt and Soften Options | Auto Reheat Options | Auto Defrost Options | Multi-Stage Cooking Option | Add-30-Seconds | Sensor Cooking Options | Quick Start: (1 – 6) | User Preferences | Power Save (No Clock Display)
| |||||
|
Information 120 V | 60 Hz | 15 A
| |||||
|
Additional Dimensions Depth with Door Open 90 Degrees: 39" | Oven Interior (HxWxD): 10-11/16"x 15-3/8"x 15-5/16" | Cutout Height: 16-1/2" | Cutout Width: 24" | Cutout Depth (Max.): 13"
| |||||
Door Hinge: Left
Weight
26.76 kg
Lighting
LED Lighting
Ventilation
Y
Filters
2 Charcoal Filters
CFM
105/300 CFM
Exhaust Fan Speeds
2 speeds
Sensor Cooking
Y
Turntable
Y
Interior Light
Y
Auto Defrost
Y
Control Lock
Y
Color
White
Capacity
1.4 Cu. Ft.
Cooking Power
1000 W
Power Levels
9
Manufacturer Color
White
Door Hinge
Left
Warranty
1-Year Parts and Labor
Depth (Without Handle)
41.11 cm
Weight
27.67 kg
Height
43.18 cm
Width
60.64 cm
Class Width
22" to 23.9"
Programs
Popcorn Button | Veggies Button | Sensor Reheat Button | Potato Button | 4 Melt and Soften Options | Auto Reheat Options | Auto Defrost Options | Multi-Stage Cooking Option | Add-30-Seconds | Sensor Cooking Options | Quick Start: (1 – 6) | User Preferences | Power Save (No Clock Display)
Additional Information
Turntable Diameter: 13-5/8" | Turntable On / Off | 26 Touch Pad Buttons | Ducted / Ductless Installation Option | Cooktop Light: LED 6 light Module | Auto-Start Heat Sensor
Information
120 V | 60 Hz | 15 A
Additional Dimensions
Depth with Door Open 90 Degrees: 39" | Oven Interior (HxWxD): 10-11/16"x 15-3/8"x 15-5/16" | Cutout Height: 16-1/2" | Cutout Width: 24" | Cutout Depth (Max.): 13"
Specifications
Product Line Over-The-Range Microwave
Power Type Electric 120v
Size 1 2/5"
Installation Type Over-the-Range
Factory Sourced
Color White
Installation
Power Supply Connection Location Bottom Center
Electrical Specifications
Voltage Rating 120 V
Cooking Controls
Clock Yes
Cooking Power 1000 Watts
Defrost Time Yes
Defrost Weight Yes
Number of Power Levels 9
Ventilation System
Exhaust Fan Speeds 2
Charcoal Filter Included Yes
Removable Grease Filter Yes
Dimensions and Volume
Height 17"
Width 23 7/8"
Depth 16 3/16"
Microwave Interior Height 10 11/16"
Microwave Interior Width 15 3/8"
Microwave Interior Depth 15 5/16"
Microwave Capacity 1.4 Cu. Ft.
Safety Certifications and Approvals
UL Listed Yes
Internal Specifications
Interior Color White
Turntable Diameter 13 63/100"
Microwave Control Features
+ 30 Seconds Yes
Controls
Control Lock Yes
General Specifications
Product Weight 56.05 lbs
Prop 65 Label Yes
Warranty - Labor 1 Year
Warranty - Parts 1 Year
Microwave Cooking
Melt / Soften Yes
Popcorn Yes
Potato Yes
Sensor Cooking Yes
Veggies Yes
Light System
Lighting Type LED
While we do our best to make sure our dimension data is accurate, errors sometimes do occur in all cases, dimensions should be confirmed by reviewing the manufacturer supplied dimension drawing and/or cut sheet.
Weight
26.76 kg
Lighting
LED Lighting
Ventilation
Y
Filters
2 Charcoal Filters
CFM
105/300 CFM
Exhaust Fan Speeds
2 speeds
Sensor Cooking
Y
Turntable
Y
Interior Light
Y
Auto Defrost
Y
Control Lock
Y
Color
White
Capacity
1.4 Cu. Ft.
Cooking Power
1000 W
Power Levels
9
Manufacturer Color
White
Door Hinge
Left
Warranty
1-Year Parts and Labor
Depth (Without Handle)
41.11 cm
Weight
27.67 kg
Height
43.18 cm
Width
60.64 cm
Class Width
22" to 23.9"
Programs
Popcorn Button | Veggies Button | Sensor Reheat Button | Potato Button | 4 Melt and Soften Options | Auto Reheat Options | Auto Defrost Options | Multi-Stage Cooking Option | Add-30-Seconds | Sensor Cooking Options | Quick Start: (1 – 6) | User Preferences | Power Save (No Clock Display)
Additional Information
Turntable Diameter: 13-5/8" | Turntable On / Off | 26 Touch Pad Buttons | Ducted / Ductless Installation Option | Cooktop Light: LED 6 light Module | Auto-Start Heat Sensor
Information
120 V | 60 Hz | 15 A
Additional Dimensions
Depth with Door Open 90 Degrees: 39" | Oven Interior (HxWxD): 10-11/16"x 15-3/8"x 15-5/16" | Cutout Height: 16-1/2" | Cutout Width: 24" | Cutout Depth (Max.): 13"
