Description
About this Product
Thermador 30” Liberty® Masterpiece® Induction Cooktop – Features 4 cooking elements with HeatShift® for quick temperature changes and MoveMode® for flexible cooking zones.
Features
- TWO EXTRA-LARGE LIBERTY® COOKING ZONES — Two extra-large Liberty® cooking zones allows more space and flexibility in placing larger cookware.
- HeatShift® — Perfect for recipes that require moving from a sauté to a simmer. HeatShift® divides your cooktop into three preset heat zones that allow you to change the power level by simply moving the pot.
- MoveMode® — MoveMode® allows you to easily move your pot across the cooktop, and the power level will automatically transfer.
- PowerBoost®. — PowerBoost® increases element power by up to 50%, saving time to heat up pots or boil water quicker.
- CookSmart® (5-PRESET TEMPERATURE LEVELS) — CookSmart® ensures optimal results with 5 pre-set temperature levels programmed for cooking different types of food.
- INSTANTANEOUS CHANGES IN TEMPERATURE WITH INDUCTION — Superior Responsiveness: Induction technology allows instantaneous temperature changes as the power level is adjusted. Induction automatically recognizes the size, shape and position of your cookware on the cooktop. The cooktop is easy to clean and provides superior responsiveness.
- WI-FI ENABLED FOR CONVENIENT REMOTE MONITORING. — Wi-Fi Enabled cooktop allows for convenient remote monitoring with access to cooktop programs and settings via the Home Connect® app.
Documents
Product Sheet (en)
Dimensions Guide (en)
Owner's manual (en)
Installation guide (en)
Additional documents(en)
Highlights
Hotplate Control Settings: 17 Power Levels | Timer: Kitchen Timer, Stop Watch | Frying Sensor | Cooktop Hood Sync
Specifications
| Burners/Elements | 4 | Elements | Smoothtop | Height | 9.8 cm |
| Width | 78.8 cm | Depth | 54.0 cm | Weight | 17.69 kg |
| Class Width | 30" | Digital Display | Y | Control Lock | Y |
| Wi-Fi | Y | Fuel Type | Electric Induction | Type | Built-In |
| Series Name | Liberty® Masterpiece® Collection | Manufacturer Color | Titanium Grey | Color | Grey |
| Warranty | Limited Warranty, Entire Appliance, Parts and Labor: 2 Years | ||||
| Power Output 1 – Power of Back Left Heating Element: 2,200 W / 3,600 W (In Boost) | 2 – Power of Front Left Heating Element: 2,200 W / 3,600 W (In Boost) | 3 – Power of Back Right Heating Element: 2,200 W / 3,600 W (In Boost) | 4 – Power of Front Right Heating Element: 2,200 W / 3,600 W (In Boost) | Power of Left Area + 1A FlexPlus™ Left Heating Element: 3,300 W / 3,600 W (In Boost) | Power of Right Area + 3A FlexPlus™ Right Heating Element: 3,300 W / 3,600 W (In Boost) | |||||
| Burner/Element Size Dimension of Back Left Heating Element: 8 1/2" x 7 1/2" | Dimension of Front Left Heating Element: 8 1/2" x 7 1/2" | Dimension of Back Right Heating Element: 8 1/2" x 7 1/2" | Dimension of Front Right Heating Element: 8 1/2" x 7 1/2" | Dimension of FlexPlus™ Left Heating Element: 3 9/16" x 11 1/4" | Dimension of FlexPlus™ Right Heating Element: 3 9/16" x 11 1/4" | |||||
| Information Watts (W): 6,240 / 7,200 W | Circuit Breaker (A): 30 A | Volts (V): 208 / 240 V | Frequency (Hz): 60 Hz | Conduit: 37" Flexible 3-Wire | |||||
| Additional Dimensions Required Cutout Size (HxWxD) (in): 3 7/8" x 28 3/4" x 19 7/8" | Minimum Distance From Counter Front (in): 2 1/4" | Minimum Distance From Rear Wall (in): 2" | |||||
| Technologies MoveMode® | CookSmart® | PowerBoost® | PanBoost® | MoveMode® | Home Connect® (Wi-Fi Enabled) | Remote Diagnostics | |||||
